if anyone needs vehicle wire info or component locating you can pm me or sent an email to [email protected]. I been in the car audio and security business for over 15yrs. and have alot of custom build under me.
now question is a stupid one. the wrong wire could cost you hundreds or even thousands.

This service is going to be free for the time being. in the future i my add a fee per page. just a thought

Hey Mate,



I'm looking for an easy connection for an 06 Hyundai Sonata for the VSS and reverse light connections. Regretfully the posting for the VSS was incorrect on avic411 http://www.avic411.com/forum/viewtopic. ... ght=sonata.



Thanks much for the help,



Cheers!!

The other option is just to head on over to the12volt.com the info is probably there if it's not, I don't see too many people trying to charge you for it either.

can you tell me which wire is the VSS wire for a 2003 Ford Explorer? My installer can't seem to find it.

Should be a gray/black wire in the vehicles radio harness. Can also get it at the gem too. Though getting it at the radio harness is alot easier.

thank you much

where are the vss, reverse and parking barake wires? and what color are they? thanks

Yes I would also like to know where to find the VSS wire on a 1997 Ford Explorer XLT v8

Thanks!

anybody out there know reverse wire and VSS for 2007 Suburban???

Where is VSS wire for a 2004 C5 Corvette coupe with automatic.

Thanks

2004 corvette

Reverse Light dk. blue - BCM, pink 32 pin plug, pin C1
Notes: The BCM is in the passenger side footwell, under the carpet.

Speed Sense dk. green/white cluster or PCM, red plug, pin 50
Notes: The PCM is located on the passenger side of the engine compartment. Remove the right front tire and remove the access panel in the inner fender to access the PCM.

hi,

what is the vss wire for a 2001 honda accord v6.
also what is the reverse wire color? or back up wire as well.

2001 Accord

Reverse Light green/black + driver side fuse box

Speed Sense blue/white ECM
Notes: Located at the first plug on the ECM, it is a 32 pin gray plug. The ECM plugs can be accessed by pulling up the carpet on the passenger side of the center console. There are 4 plugs total.

wow thank you!

when you say green/black does that mean the wire is green with black accent or black line or do you mean black wire with green accent/ or green line on the black wire?

same question for the ecm wire?

basically is it a blue wire with white line or white wire with a blue line on it?

sorry for this extra question. i have not opened up yet but i needed to know 100% what i am looking for before i dive into a 2 day fun with the car on installs and clean ups. the car is a daily for my GF so i dont have it till the day i do it. which is this thursday and friday.

thanks again.

THe first color will be the color of the majority of the wires insulation. The second color will be the color of the stripe on the wire. All in all not a hard car to work on. Good luck and happy installing.

i need the VSS wire for an 95 4Runner SR5.

thanks

VSS and Reverse wirse on 1995 BMW 530i auto.

Thanks.

I would like to find out about the vss wire for the 2002 nissan pathfinder le. Had installer look at it 2 times so far and nothing seems to be worng but I dont have a speed pulse?

Thanks in advance and keep up the good work!

MH

VSS wire for 2001 Lexus IS300.

Thanks a bunch!!!

2002 Nissan Pathfinder

Reverse Light yellow + kick panel, harness to rear

Speed Sense white/blue cruise module in Drivers Kick Panel

Merry xmas

2001 Lexus IS 300

Speed Sense red/yellow abs and traction ECU
Notes: The ABS and traction ECU is above the driver kick panel.

Merry xmas

Reverse Light yellow + kick panel, harness to rear

Speed Sense white/blue cruise module in Drivers Kick Panel

Does that mean that there are two wires in two different places that make up the vss and speed pulse wires that need to be connected to the unit? Please forgive my ignorance. But it may turn out that it is I or the installer that screwed up the first two times that tries to fix it.

Thanks much! -Matt-

No that's 2 different wires. One of them is the reverse wire which tells the avic when the car is in reverse and the other one labeled speed sense is the vss wire you're looking for. I just post both out of habit. Saves people from asking for the vss and then later having to ask for the reverse wire.

The color listed the first one is the color of the majority of the wire, the second color is the color of the stripe on it. If the installer knows anything just show him the post and he'll know what to do with the info.

2005/2006 Acura RSX automatic please? Also, where would the reverse wire go?

Thanks man.

2005 Acura RSX

Reverse Light green + kick panel, harness to rear

Speed Sense blue/white ECM/PCM, white 31 pin plug, pin 26
Notes: The ECM/PCM is under the glove box.

If the vehicle is equipped with cruise control, the wire can also be found at the cruise control unit to the left of the gas pedal.

Merry xmas
